Audiolab 9000P Power Amplifier
The Audiolab 9000P is a flagship stereo power amplifier delivering exceptional performance with 100 watts per channel into 8Ω. Featuring advanced Class AB topology, dual mono construction, and premium components throughout, the 9000P provides effortless power and refinement for the most demanding loudspeakers.
Key Features
- High-Current Class AB Design – 100W per channel (8Ω), 200W per channel (4Ω) for dynamic headroom
- Dual Mono Architecture – Completely separate left/right channel circuits and power supplies
- Balanced & Unbalanced Inputs – XLR and RCA connectivity for flexible system integration
- Premium Output Stage – High-current bipolar transistors with advanced thermal management
- Oversized Power Supply – Massive toroidal transformer with 40,000µF reservoir capacitance
- 12V Trigger – Remote power-on integration with preamp or processor
- Bridgeable to Mono – Combine two 9000P units for 400W mono operation
Technical Specifications
|
Specification |
Details |
|
Amplifier Type |
Class AB stereo power amplifier |
|
Power Output (8Ω) |
100W per channel (both channels driven) |
|
Power Output (4Ω) |
200W per channel (both channels driven) |
|
Power Output (Bridged Mono) |
400W into 8Ω |
|
Frequency Response |
10Hz – 50kHz (±0.5dB) |
|
THD+N |
<0.003% (1kHz, rated power, 8Ω) |
|
Signal-to-Noise Ratio |
>115dB (A-weighted, ref. rated power) |
|
Channel Separation |
>90dB (1kHz) |
|
Input Impedance |
47kΩ (RCA), 20kΩ (XLR) |
|
Input Sensitivity |
1.0V RMS (RCA), 2.0V RMS (XLR) for rated output |
|
Damping Factor |
>500 (20Hz – 20kHz, 8Ω) |
|
Gain |
29dB |
|
Analog Inputs |
1× RCA unbalanced, 1× XLR balanced per channel |
|
Speaker Outputs |
High-quality binding posts (bi-wire compatible) |
|
Trigger Input |
12V DC (3.5mm jack) |
|
Power Supply |
Dual mono toroidal transformers, 40,000µF capacitance |
|
Output Devices |
High-current bipolar transistors (complementary pairs) |
|
Protection |
DC offset, short circuit, thermal overload |
|
Cooling |
Large heatsinks with convection cooling (no fan) |
|
Dimensions (W×H×D) |
445 × 175 × 420 mm |
|
Weight |
18.5 kg |
|
Power Consumption |
600W maximum, <1W standby |
|
Finish |
Black or Silver anodized aluminum |
What's in the Box
- Audiolab 9000P Stereo Power Amplifier
- IEC power cable
- Quick start guide
- Warranty card
Perfect For
Audiophiles seeking reference-grade amplification with effortless power delivery, high-end two-channel systems requiring exceptional control and dynamics, demanding loudspeakers that benefit from high current capability, and home theater enthusiasts building premium stereo or multi-channel configurations with bridgeable mono operation.
| Price | R 20,990.00 |
